Maya came to us in early autumn with a problem that many small television teams will recognise. Her regional news programme was recorded in a converted storage hall, and the studio had grown by accident rather than by plan. The desk sat too close to the back wall, the cameras tripped over each other during two-shot moves, and the gallery was a room at the far end of a corridor with no sightline to the floor.
She was not asking for a new building. Her budget was modest and the programme could not stop broadcasting while work went on. What she wanted was a written plan she could show her commissioning editor, with a floor layout, a gallery arrangement and an equipment list that made sense together. That is the core of what we mean by broadcast studio design: deciding where everything goes before anyone buys or lifts anything.
Our first visit involved very little talking and a great deal of measuring. We recorded ceiling height, the position of every door and power outlet, the floor surface, and the noise that crept in from the loading bay outside. From the sound side, which is my own part of the work, I noted how much the hall rang when someone clapped, because a reverberant room shapes how the set can be furnished.
Maya sat with us while we did this and described a normal recording day: who stands where, how guests arrive, how long the changeovers between items take. Those details mattered more than the dimensions. A studio plan drawn from measurements alone describes a room; a plan drawn from a recording day describes a programme. We left with a notebook of both and agreed to return with two layout options rather than one.
- Ceiling height and rigging points
- Power, network and cable routes
- Background noise from neighbouring spaces
- The real order of a recording day
The first option kept the desk where it was and added a second camera position at an angle. It was cheap and quick, but it left the gallery exactly as awkward as before. The second turned the set through ninety degrees, moved the presenter away from the reflective back wall, and placed the gallery behind a window at the side of the floor so the director could see the talent directly.
Maya chose the second, and not simply for the window. Turning the set gave the cameras a longer throw, which meant gentler lens choices and less distortion on the presenter. It also gave us a quiet corner for a small guest sofa without crossing any cable runs. We drew both options to scale on paper so that she could walk the floor with tape and feel the difference before committing.
A gallery is a working room for several people, and its layout decides how calmly a live programme runs. We placed the director and vision mixer side by side with a clear view of the monitor wall, and put sound at the end of the desk where the producer could lean over without blocking the mixer. Intercom positions were marked on the plan so that no one had to reach across anyone else.
As the person responsible for audio, I argued for one thing in particular: a proper listening position with the monitors at a sensible distance, rather than speakers squeezed into whatever space remained. Maya agreed once she heard the difference on a short test. Small decisions like these rarely appear in a brochure, yet they are what a crew notices on the fortieth recording rather than the first.
- Director and vision mixer side by side
- Sound position with a true listening distance
- Intercom points marked before installation
Once the layout was settled, we turned it into a written equipment list, ordered by what the plan actually required instead of what a catalogue suggested. Each line named the item, where it sat on the drawing, and why it was there. Maya could see which items were essential for the first phase and which could wait for the following budget year.
We were careful not to specify more than the room could use. A smaller studio does not need the largest camera package, and the list reflected that. Where she already owned usable equipment, we reused it and noted how it should be repositioned. The finished document ran to several pages, yet she told us it was the first technical paper she had read straight through without needing a translator at her side.
The refit was carried out over two quiet weeks between series, so the programme never missed a transmission. On the first recording in the new arrangement, the changeover between the main desk and the guest sofa dropped noticeably, and the director no longer had to shout across a corridor to be understood by the floor manager.
Maya has since told us that the most useful result was not any single piece of equipment. It was having a plan on paper that her whole team understood, which let them make later decisions with confidence. That is what I take from her case: good studio design is mostly patient preparation, done before the cables are cut, and it is the part of the work that shows least in the finished picture.
Maya's studio is still a modest room, and it still records the same programme. What changed is that its layout, gallery and equipment now follow from how the team actually works. If you are planning a similar refit, start by describing a real recording day to whoever draws the plan; the floor, the cameras and the gallery will follow from that far more reliably than from a list of products.
